| Min. Order: | 1 Set/Sets |
|---|---|
| Payment Terms: | T/T |
| Place of Origin: | Zhejiang, China (Mainland) |
| Means of Transport: | Ocean, Air, Land |
| Production Capacity: | 1000pcs/month |
| Packing: | Carton, Plywood Case |
| Delivery Date: | 3 days after payment | Product Material: | Stainless Steel |
|---|---|---|---|
| Special Function: | Others | Position: | Room |
| Open Style: | Sliding | Brand Name: | ODY |
| OEM: | YES | Door Track: | Aluminum alloy |
| Door leaf: | Double or single leaf | Door weight: | 50kg×2 Max |
| Ambient temperature: | -20°C to 50°C | Manual push force: | 20N-30N |
| Motor: | No motor | Speed: | Adjustable |
1. Humanization design, save energy and environmental protection.
2. Adjust the close speed just need a screwdriver.
3. Open/close smoothly, low noise.
4. Single leaf, double leaf and telescopic door.
5. Easy installation, convenience.
6. Do not need too much space. Application: kitchen, rest room, bathroom etc.
Self Closing Sliding Door
| Door type | 1 leaf, single | 2 leaf, bi-parting |
| Recommended max. door weight | 80×1 kg | 50kg×2 |
| Tracking length | 2200mm | 2200mmx2 |
| Door width | 650mm-1200mm | 650mm-1000mm |
| Manual push force | 20N | 30N |
| Ambient temperature | -20°C to 50°C | -20°C to 50°C |
1. Features
Humane design and energy saving. No motor, no drive device, users can open the
door with hand and the door will close automatically.
Closing force and speed can be easily adjusted with a single screwdriver. Smooth
close and open with low noise. It can match single door leaf or double door leaves. Easy to install and convenient to use. The door doesn't need much space.
2. Appliances
It is mainly used for kitchen door and separated door of home, Hospital, Hotels,
offices etc. No special maintenance are required.
2 leaf, bi-parting
